Linear Chevron Gate – Laser Cut Design, DXF, SVG, AI, PDF, EPS | Downloadable

Description

Create an elegant and luxurious gate for villas or homes with the Linear Chevron Gate digital vector design. This design showcases rich, symmetrical floral ornamentation centered on each door panel, enhanced with intricate arabesque patterns throughout the gate structure. The curved black areas in the design are ideal for handle installation, offering both aesthetic appeal and practical functionality for smooth opening and closing.

This design began as a detailed hand sketch, which was then digitally refined using advanced design software to ensure high precision. It’s fully optimized for use with laser cutting machines, fiber lasers, plasma cutters, and water jet machines—perfect for crafting high-quality metal gates.

Versatile Applications

Beyond gate creation, this design can also be used for other architectural elements. It’s suitable for producing large decorative windows with protective metal overlays behind glass or polycarbonate sheets, providing both security and visual enhancement to building facades.

Important Note

This is a digital product—no physical item will be shipped. After purchasing, you will be able to download the files immediately for use with compatible CNC cutting machines.

Machinist Notes

• All vector files have been reviewed and tested by a professional machinist to ensure compatibility with various CNC systems.

• The design is fully editable in any CAD software—resize as needed while maintaining the original aspect ratio.

• See the product’s “Additional Attributes” section for detailed specifications.

Compatible Materials

You can use this design to cut a wide range of materials, including:

• Metal Sheets

• Iron

• Stainless Steel

• Wood

License Information

All artwork purchased from Designifier includes a Fabricator’s License, which allows you to produce physical goods for personal or commercial use—either for yourself or for clients. However, redistribution or resale of the digital files themselves is strictly prohibited.

Included File Formats

Upon purchase, you will receive a ZIP file containing the following formats:

• DXF

• AI

• SVG

• EPS

• PDF

The ZIP file makes downloading and uploading easier and can be extracted using standard decompression tools.
